WATER SEPARATOR SAND MACHINE

The servo linear back and forth principle,the movement of the machine according to the process requirements can be intermittent orientation operation,and  equipped  with   a  frequency   converter  to   control  the mechanical  speed,depending  on  the  process  requirements  of  the product,the product can be fine throwing operations,only one worker loading and unloading parts,the operation is simple and convenient,no technical requirements for the operator.

Category:
名称Name 单位Unit 规格Specifications
主电机 Main motor KW 2.2
夹具装置 Jig device 2
砂带规格 Belt specification mm 2100×50
产品运行方式 Product operation mode 伺服电机控制方位,360度旋转Servo motor controls orentation and rotates 360 degrees
主电机 Main motor KW 2.2
产品旋转 Product rotation w 400(伺服)+60行星减速机400(servo)+60 planetary reducer
产品进退 Product advance and retreat w 6585-29点热品
工件长度要求 Workpiece length requirement mm 1000以内
设备尺寸 Equipment size mm 1950*1900*1900
